| Model Parameter | Specification Details |
|---|---|
| Model | ARC series |
| Vacuum Chamber | SUS304, φ600mm-1200×600-1200mm (H) |
| Substrate Dome Size | Customizable to customer needs |
| Rotation Speed | 10 rpm to 50 rpm (Variable) |
| Arc Evaporation Source | 2 to 16 sets |
| Vacuum System | Roughing Pump, Diffusion Pumps or Turbo Molecular Pump + Mechanical pumps |
| Property | Value |
|---|---|
| Ultimate Pressure | 5.0×10⁻⁴ Pa or lower |
| Pump Down Rate | 25 minutes (Atm. to 5.0×10⁻³ Pa) |
| Substrate Heater | Up to 550°C (max) |
| Layout Dimensions | Approx. 5000mm (W)×6500mm (D)×3500mm (H) |
| Power Requirements | 3-phase, 380V, 50/60Hz, 100-180kVA |
| Cooling Water Flow | 140 L/min or greater |
The system is designed for high-tech surface coating of metal, glass, and ceramics, making it highly versatile for various industrial applications.
By utilizing arc deposition technology, the machine applies a hard PVD coating that significantly improves the workpiece's hardness, wear resistance, and resistance to environmental factors.
Yes, the chamber size can be customized ranging from φ 600mm to φ 1800mm to accommodate different product dimensions and production needs.
The system can deposit various functional and decorative films, including TiN, TiC, CrN, ZrN, and TiCN, using multiple arc sources.
The system can achieve a vacuum level from atmospheric pressure to 5.0×10⁻³ Pa in approximately 25 minutes, ensuring high efficiency in production cycles.
The equipment typically requires a 3-phase, 380V power supply (100-180kVA) and a cooling water flow rate of 140 L/min or greater for optimal operation.
